1、The entire machine is controlled by a high-speed microcontroller, with a high degree of automation and easy operation.

2、The instrument adopts new power supply technology, with a wide measurement range.

3、The protection function is complete, which can reliably protect the impact of back electromotive force on the instrument, and the performance is more reliable.

4、Fast response speed, stable instrument measurement data, and automatic data refresh during the instrument testing process.

5、Intelligent power management technology ensures that the instrument always operates at the minimum power state, effectively reducing internal heating and saving energy.

6、The instrument has an internal power on clock.

7、The instrument has an internal power on memory that can permanently store data.

1、measuring range：

2、output current： automatic、10A、 5A、1A、300mA、100mA、<5mA

3、resolution ratio：0.1μΩ

4、accuracy： 0.2%

5、Opening voltage：5A、10A：2.5V；Other gears：battery voltage；

6、output power：25W

7、operation temperature：0~40℃

8、Working humidity：<90%RH

9、Overall dimensions: length230mmX width 155mmX high60mm

10、weight：1.2kg
